Automatic Voltage Regulator

lntroduction

PC Auto New AVR

Automatic Voltage Regulator

This automatic voltage regulator is widely used in various industries,small office equipment,refrigerator,electric fan,computer,pump,air conditioner and other household appliances.
ADVANTAGE
1. It is a fully automatic voltage REGULATOR which can automatically stabilize voltage with just one tap, which is very convenient and cool.
2. Although this automatic voltage regulator is wrapped with sturdy sheet metal, it is still very light and portable, and has very powerful functions, which is suitable for all kinds of small household appliances.
3. In addition to displaying the input voltage and output voltage, this automatic voltage stabilizer can also display the load status, and it also has a delay protection function, which is very high quality and low price.

Get A Free Quote!

Advantages

Automatic Voltage Regulator

Digital Display System

MOU is further strengthened by the inclusion of a unique and efficient digital display system. You will be able to see essential details like input voltage, output voltage, and protection modes that are enabled, such as low voltage, high voltage, overload cut-off, etc. very easily. The details are displayed in such a manner that you can constantly ensure that the connected load is working in the safe voltage range displayed on the stabilizer.

Microcontrolled operation

Given the fact that even a small voltage fluctuation can damage sensitive components of your connected air conditioner, a microcontroller-based design is more than necessary. The highly efficient microcontrolled operating system facilitated by TMP ensures that the mechanism of voltage correction operates at a speed that is much faster than what conventional circuits can offer.

Smart Output Voltage Correction

The security of the TMP Wall-mounted Home AVR is further heightened with the addition of the advanced technology of its Smart Output Voltage Correction. This technology can adjust the regulation range to work in accordance with the supply voltage variation to gain the most satisfactory power regulation required for the safe functioning of the connected load.

Elegantly Designed Cabinet

Easily the most distinguishable characteristic of this stabilizer is its remarkable look - a classy and flawless finish that serves as a perfect complement to your air-conditioner； an excellent addition to your living space. In short, the stabilizer’s elegantly designed cabinet enhances your AC’s beauty, giving it a seamless overall look of sophistication. TMP is your air-conditioner’s better half - one that is not just rich in features, but aesthetically stunning across every aspect of its path-breaking design.

Get Your Solution Now!

Specifications

Automatic Voltage Regulator Parameters

MODEL	MOU(3kVA-15kVA)
INPUT VOLTAGE	AC 45V-280V
OUTPUT VOITAGE	AC 220V±10% 50/60HZ
DELAY TIME	Short Delay:3-5sec Long Deley:3-7min
PROTECTION	Over Voltage(246V±4V),Overioad,High Temperature,Short Circuit
POWER	3kVA-15kVA
FEATURE	The product of this model is a 220V fully automatic voltage regulator.design of imitating computer case, with concise and generous appearance .Display of LED digital design.it is characterized by stable work, high pressure regulation speed and wide voltage regulation range.
APPLICATION	It is widely used in various industries, small office equipment,refrigerator, electric fan, computer, pump, air conditioner and other household appliances.
Power Factor	≥0.9	≥0.9	≥0.9	≥0.9
Control	5-7 relays
Digital display	show input and output voltage、Over\Low Voltage、Overload、delay、temperature	show input and output voltage、Over\Low Voltage、Overload、delay、temperature	show input and output voltage、Over\Low Voltage、Overload、delay、temperature	show input and output voltage、Over\Low Voltage、Overload、delay、temperature
Temperature protection	yes	yes	yes	yes
Short circuit&over load	air-switch/（fuse：500-2000va）	air-switch/（fuse：500-2000va）	air-switch/（fuse：500-2000va）	air-switch/（fuse：500-2000va）
Cooling type	FAN/Vents	FAN/Vents	FAN/Vents	FAN/Vents
Efficiency	AC 97%	AC 97%	AC 97%	AC 97%
Temperature	.-20°~55℃	.-20°~55℃	.-20°~55℃	.-20°~55℃
Humidity	<90	<90	<90	<90

Want to Get More Types, Click Here!

Voltage Regulator( Voltage stabilizer )20 Years

AC AUTOMATIC VOLTAGE REGULATOR

01.High Quality Painting For Sheet Metal

Make sure it for long term use and nice surface

02.LED/LCD DIGITAL DISPLAY DESIGN

Working status display is more intutive

03.Intelligent Running Software

According to the iferent characteristics of the load, the output voltage level and the speed of the voltage change of the voltage stabilizer can be adjusted intelligently, so that the load can be started more easily and running more smoothly.

04.High Efficiency Toroidal Transformer

Make the working loss of transformer to the minimum and save electricity

05.Perfect Software Technology for Spark Elimination

It can automatically track the change of relay parameters in real time, adjust the parameters of spark elimination, and eliminate the sparks completely.

Get Quote From The Reliable Supplier!

Function

PROTECTION FUNCTION

DELAY PROTECTION

Delay protection starting voltage stabilizer, waiting for 6 seconds to be able to work (in3-5 seconds to prevent instantaneous voltage impact on electrical appliances).

TEMPERATURE PROTECTION

Mounted on the coil temperature sensor when the sum of ambient temperature and transformer temperature is automatically cut off at 110 C, the voltage regulator automatic protection to cutoff the output.

OVERLOAD PROTECTION

When the power reaches 120%, the regulators tomatically protects and cuts off the output.

LOW VOLTAGE PROTECTION

When the output volage is lower than rated input voltage. the low wol indicator light rises and the output will be cut off.

LIGHTNING PROTECTION

When the output voltage is higher than rated input woltage. the over vol indicator light rises and the output is cut off.

Solve Your Power Problems. Inquiry Now!

Application

PRODUCT APPLICATION

They are suitable in Computer , Test equipment , Light system , Safe alarm system , Ray equipment ,Mledical equipment , Copymachine , Stereo equipment , Numerical control machine tools ,Industrial mation equipment , Color and drying equipment , Testequipmer , Hi-fi equipment etc .
